Exploded View

14
9
22

Parts Listings

Part # Description
BLH2500 Micro Apache AH-64, RTF
BLH2580 Micro Apache AH-64, BNF
1 BLH2501 Main rotor blade set: Apache AH-64
2 BLH2502 Main rotor head: Apache AH-64
3 BLH2503 Spindle set: Apache AH-64
4 BLH2504 Main rotor grip set: Apache AH-64
5 BLH2505 Rotor head linkage set: Apache AH-64
6 BLH2506 Swashplate: Apache AH-64
7 BLH2507 Ball Bearing m2.5x6x1.8: Apache AH-64
8 BLH2508 Ball Bearing m2.5x6x2.5: Apache AH-64
9 BLH2523 Apache Landing Gear Set
11 BLH2509 Ball Bearing m3x7x3: Apache AH-64
12 BLH2510 Servo linkage set: Apache AH-64
13 BLH2511 Main Shaft: Apache AH-64
14 BLH2512 Main frame set: Apache AH-64

Optional Parts

Part # Description
DX6i DSMX 6-Channel Transmitter Only
DX7s DSMX 7-Channel Transmitter Only
DX6 DSMX 6-Channel Transmitter Only
DX7 DSMX 7-Channel Transmitter Only
EN
22
2
6
15
12
13
19
16
20
18
26
23
3
7
8
5 4
26
20
11
27
17
14
21
9
Part #
15 BLH2513
16 BLH2514
17 BLH2515
18 BLH2516
19 BLH2517
20 BLH2518
21 BLH2519
22 BLH2520
23 BLH2521
24 BLH2522
25 EFLB4002S30J 400mAh 2S 7.4V 30C LiPo JST
26 SPMSH2060
27 SPMAR6335
EFLC3110
EFLC4000
Part # Description
DX8 DSMX 8-Channel Transmitter Only
DX9 DSMX 9-Channel Transmitter Only
DX18 DSMX 18-Channel Transmitter Only
18
24
1
22
Description
Anti-rotation bracket: Apache AH-64
Motor mount: Apache AH-64
Main gear: Apache AH-64
Gear drive reduction set: Apache AH-64
Brushless main motor: Apache AH-64
Servo arm set: Apache AH-64
Dual Brushless ESC: Apache AH-64
Body set w/led: Apache AH-64
Brushless tail motor: Apache AH-64
Tail rotor: Apache AH-64
Nanolite High Speed Heli Servo
®
6-Channel AS3X Nanolite Receiver
2-3 Cell LiPo Balancing Charger, 0.65A
AC to 12VDC, 1.5-Amp Power Supply
