• This device was designed to be permanently
secured and connected on a building or on a
suitable structure. The device must be permanently
secured and connected before any operation.
• Comply with all the national standards during the
device installation.
• Installation category (also called Overvoltage
Category) specifies the level of mains voltage
surges that the equipment will be subjected to.
The category depends upon the location of the
equipment, and on any surge voltage protection
provided. Equipment in an industrial environment,
directly connected to major feeders/short branch
circuits, is subjected to Installation Category
III. If this is the case, a reduction to Installation
Category II is required. This can be achieved by
use of an insulating transformer with an earthed
screen between primary and secondary windings,
or by fitting UL listed Surge Protective Devices
(SPDs) from live to neutral and from neutral to
earth. Listed SPDs shall be designed for repeated
limiting of transient voltage surges and the
following rated operation conditions: Type 2 (SPDs
permanently connected to the power network and
intended for installation on the load side of the
service equipment); Nominal Discharge Current
(In) 20kA min. For example: FERRAZ SHAWMUT,
STT2240SPG-CN, STT2BL240SPG-CN rated
120Vac/240Vac, (In=20kA). Maximum distance
between installation and reduction is 5m.
• Any device which could be installed inside the
product must comply with the current safety
standards.
• If the installation is NEMA TYPE 4X, the installer
must replace the cable glands of the product with
NEMA TYPE 4X cable glands.
• Power supply to the product must be exclusively
provided by the PoE cable (Power over Ethernet).
• For all connections, use cables that are able to
withstand temperatures of at least 75°C (167°F).
• The product is designed to house only cameras
that are properly certified according to IEC/UL
60950-1 or IEC/UL 62368-1 (7W max).
4
• A power disconnect device must be included
in the electrical installation, and it must be very
quickly recognizable and operated if needed.
• To connect the power supply line use the
appropriate junction-box (UPTJBUL). For further
information, refer to the product use and
installation manual.
• Use Listed tube crimping lugs for the connection
of the network conductors to the terminals. The
copper tube crimping lugs must be suitable for
the type of installation (from -20°C (-4°F) a +80°C
(+176°F) min., V-0). Copper tube crimping lugs
examples: RP, BP o YP (Cembre).

4 Identification

4.1 Product description and type
designation
The HOV Hi-PoE IPM housing optimally operates
with POE and Hi-POE technology, using the power
supplied by the Ethernet cable as the sole source
of power for all connected devices, thus ensuring
maximum efficiency and flexibility of the network
system as well as user-friendly installation and low
costs.
The innovative IPM (Intelligent Power Management)
system enables extremely quick and easy installation
with the use of a single Ethernet connecting cable.
The Hi-POE IPM system automatically detects all
the options, like heating, fan and illuminator and
then autonomously balances the power to ensure
suitable distribution of the same to the connected
devices. This guarantees the optimal operation of the
IP camera between -30°C (-22°F) and +60°C (140°F),
with heat regulation and cold start (activation at low
temperature).
The IPM system offers an opportunity to refit
analogue systems with already installed housings by
simply changing the slide and internal electronics.
This enables the digital conversion, speeding up
the installation and thereby minimizing costs and
environmental impact.

4.2 Product marking

See the label attached to the product.
