4 Identification

4.1 Product description and type
designation
Robust and large aluminum housing designed to fit
1/2", 1/3" and 1/4"cameras with optics of different
kinds.
It can be used for a variety of applications, for the
monitoring of urban and highways, in particular if
coupled with the PTH900 P&T series .
The opening system allows an easy access for
installation and servicing.
It can be installed with cable sheaths, instead of
regular cable glands using the junction box for the
wiring harness.
A wide range of accessories for mounting the
equipment is available thereby satisfying all
installation needs.

4.2 Product markings

See the label attached to the product.
5 Preparing the product for
use
Any change that is not expressly approved
by the manufacturer will invalidate the
guarantee.

5.1 Safety precautions before use

CAUTION! The electrical system to which the
unit is connected must be equipped with a
15A max automatic bipolar circuit breaker.
The minimum distance between the contacts
must be 3mm (0.1in). The circuit breaker must
be provided with protection against the fault
current towards the ground (differential) and
the overcurrent (magnetothermal).
4

5.2 Unpacking and contents

5.2.1 Unpacking

When the product is delivered, make sure that the
package is intact and that there are no signs that it
has been dropped or scratched.
If there are obvious signs of damage, contact the
supplier immediately.
Keep the packaging in case you need to send the
product for repairs.
5.2.2 Contents
Check the contents to make sure they correspond
with the list of materials as below:
• Housing
• Housing equipment:
• Allen wrenches
• Spacers
• Bolts and screws
• Desiccant bag
• Instructions manual
5.3 Safely disposing of packaging
material
The packaging material can all be recycled. The
installer technician will be responsible for separating
the material for disposal, and in any case for
compliance with the legislation in force where the
device is to be used.
When returning a faulty product we recommend
using the original packaging for shipping.
5.4 Preparatory work before
installation

5.4.1 Attaching the bracket

The product must be fastened with suitable
equipment. The fastening means must
guarantee the mechanical seal when a force
equal to at least 4 times the weight of the
device is applied.
