Basic guide to using the menu system
Selecting a menu
 Turn the Rotating/ Pressing knob to the right/left to select the desired
menu option.
Note: The active menu item is shown with a black background on the
display.
Editing values
 Press the Rotating/ Pressing knob
 Turn the Rotating/ Pressing knob to change the value (the magnitude
of the change is dependent on the speed at which the knob is turned).
 Press the Rotating/ Pressing knob again to complete the process.
Exiting a menu
 Press the SET button.
 Current values are stored.
Next-highest menu level is displayed.
 Press the ESC button.
 Current values are not stored.
Next-highest menu level is displayed.
Note: Some menu items do not contain values that can be stored. Select
SET or ESC to exit the menu.
Note: Certain menu items have functionality that varies from or adds to
that described above.
Display screen during the distillation process
Each operating mode has its own dedicated display screen. The following
display characteristics are common:
- When a distillation is in progress it is not possible to leave the active
display indicated.
- Press SET or ESC to exit the active display mode when no distillation is in
progress. This will return the display to the main menu.
Error messages
 Press ESC to acknowledge the fault if an error message appears on the
display.
 The error message will disappear.
Note: In the case of serious faults, an additional display message will
appear indicating that the device must be switched off and only swit-
ched back on again when the fault has been rectified.
The unit is ready for service when the
mains plug has been plugged in.
Switching on the device
 Switch on the device on the right side of the device by the mains plug
(fig.25).
 Device functions activated.
Note: The heating bath must also be switched on.
All manuals and user guides at all-guides.com
Commissioning
Fig. 25
Functional description (in as-delivered state)
Factory settings
The values specified below correspond to the as-delivered state (display
output/factory language setting is English)
 The system check is performed while the start screen is displayed; this
takes no more than 30 seconds.
 The main menu will appear after a few seconds.
 Turn the Rotating/ Pressing knob to the right/left to select a menu
option.
 Confirm the selection by pressing the Rotating/ Pressing knob.
"Settings" menu
The following options are available from the "Settings" menu.
 Turn the Rotating/ Pressing knob to the right/left to select a menu
option.
 Confirm the selection by pressing the Rotating/ Pressing knob.
