Table 21: LED's on the control unit's keys
Led 1
Off
On
It flashes
Led L2
Off
On
It flashes
Led L3
Off
On
It flashes
Led L4
Off
On
It flashes
Led L5
Off
On
It flashes
Led L6
Off
On
It flashes
Led L7
Off
On
It flashes
Led L8
Off
On
It flashes

7.8) Accessories

The following optional accessories are available for ROBUS:
• SMXI or SMXIS 433.92MHz Radio receiver with digital Rolling code
(fig. 30).
• PS124 PS124 24 V Buffer battery - 1,2Ah with integrated charger
battery (fig. 31).
30
22 – English
Description
During normal operation the device indicates "Automatic Closing" is not active
During normal operation the device indicates "Automatic Closing" is active.
• Function programming in progress.
• If it flashes together with L2, it means that the user must carry out the device recognition phase (refer to
Paragraph "4.3 Recognition of the devices").
Description
During normal operation the device indicates "Close after photo" is not active.
During normal operation the device indicates "Close after photo" is active.
• Function programming in progress.
• If it flashes together with L1, it means that the user must carry out the device recognition phase (refer to
Paragraph "4.3 Recognition of the devices").
Description
During normal operation the device indicates "Always close" is not active.
During normal operation the device indicates "Always close" is active.
• Function programming in progress.
• If it flashes together with L4, it means that the user must carry out the leaf length recognition phase
(refer to Paragraph "4.4 Recognition length of the leaf").
Description
During normal operation the device indicates "Stand-by" is not active.
During normal operation the device indicates "Stand-by" is active.
• Function programming in progress.
• If it flashes together with L3, it means that the user must carry out the leaf length recognition phase
(refer to Paragraph "4.4 Recognition length of the leaf").
Description
During normal operation the device indicates "Thrust" is not active.
During normal operation the device indicates "Thrust" is active.
Function programming in progress.
Description
During normal operation the device indicates "Pre-flashing" is not active.
During normal operation the device indicates "Pre-flashing" is active.
Function programming in progress.
Description
During normal operation the device indicates that the CLOSE input activates a closing manoeuvre.
During normal operation the device indicates that the CLOSE input activates a partial opening manoeuvre.
Function programming in progress.
Description
During normal operation the device indicates that ROBUS is configured as Master.
During normal operation the device indicates that ROBUS is configured as Slave.
Function programming in progress.
• SOLEMYO solar power system (for installation and hookup, refer to
the product's user manual)
