Input LED Parameter
L6 Open Partially
Maintenance
L7 warning
L8 List of
malfunctions
Note: " " represents the factory setting
All the parameters can be adjusted as required without any contraindication; only the adjustment of the "motor force" could require special
care:
• Do not use high force values to compensate for points of abnormal friction on the leaf. Excessive force can compromise the operation of
the safety system or damage the leaf.
• If the "motor force" control is used to assist the impact force reduction system, measure the force again after each adjustment in compli-
ance with EN standard 12445.
• Wear and weather conditions may affect the movement of the gate, therefore periodic force re-adjustments may be necessary.

7.2.4) Level two programming (adjustable parameters)

The adjustable parameters are factory set as shown in the table 7, with: "
8. Follow the procedure carefully, as there is a maximum time of 10 seconds between pressing one key and another. If a longer period of
time lapses, the procedure will finish automatically and memorize the modifications made up to that stage.
Table 8: changing the adjustable parameters
1. Press the key [Set] and hold it down (approx. 3 s
2. Release the [Set] key when L1 LED starts flashing
3. Press key [s] or [t] to move the flashing LED onto the input LED representing the
parameter which is to be changed
4. Press the key [Set], and hold it down during step 5 and 6
5. Wait approx. 3 seconds, after which the LED representing the current
level of the parameter which is to be modified will light up.
6. Press key [s] or [t] to move the LED representing the parameter value.
7. Release the key [Set]
8.
Wait 10 seconds before leaving the programme to allow the maximum time to lapse.
Note: Points 3 to 7 can be repeated during the same programming phase in order to set other parameters
14 – English
LED (level) Value
L1 0,5 m
L2 1 m
L3 1,5 m
L4 2 m
L5 2,5 m
L6 3 m
L7 3,4 m
L8 4 m
L1 Automatic (depending on the severity of the
manoeuvre)
L2 1000
L3 2000
L4 4000
L5 7000
L6 10000
L7 15000
L8 20000
L1 1 manoeuvre result
a
L2 2 manoeuvre result
a
L3 3 manoeuvre result
a
L4 4 manoeuvre result
a
L5 5 manoeuvre result
a
L6 6 manoeuvre result
a
L7 7 manoeuvre result
a
L8 8 manoeuvre result
a
Description
Adjusts the measurement of the partial
opening. Partial opening can be controlled
with the 2nd radio command or with
"CLOSE", if the "Close" function is present,
this becomes "Open partially".
Adjusts the number of manoeuvres after
which it signals the maintenance request
of the automation (see paragraph "7.4.3
Maintenance warning").
The type of defect that has occurred in the
last 8 manoeuvres can be established (see
paragraph "7.6.1 Malfunctions archive").
" However, they can be changed at any time as shown in Table
Example
SET
3s
L1
SET
or
SET
or
SET
10s
