trimmer head cover while depressing the latches.
Q
Remove the line trimmer head cover, knot and spool then set
aside.
Q
Place the line trimmer head on the drive shaft. Make sure the
line trimmer head is fully seated.
Q
Install the hex bolt into the opening on the drive shaft and
secure using the hexshaped opening in the knob to tighten.
NOTE: Only use the knob to tighten the bolt. The use of other tools
may allow over tightening of the bolt, which could damage the line
trimmer head.
Q
Install the spring into the line trimmer head and push down to
seat.
Q
Installing the spool. For the RLT430SES curved line trimmer
attachment, the spool should be placed so "this side out
for curved shaft" is visible. If you are using a straight shaft
attachment with the Real easy cutting head the spool should
be placed "the side out for straight shaft" is visible.
Q
Replace the knob in the spool.
Q
Replace the line trimmer head cover, aligning latches with
openings in the line trimmer head. Press cover and line
trimmer head together until both latches snap into openings
securely.
Q
Install line as described in the next section of this manual.
Engine Displacement
Cutting Path Diameter
String Diameter
Blade Diameter
Blade type
Mass(without fuel with string head)
Mass(without fuel, with blade head)
Volume (fuel tank)
Volume (oil tank)
Maximum engine perform
(in accordance with ISO8893)
Maximum rotational frequency of the spindle
Engine speed (rotational frequency) at recommended max.
spindle rotational frequency
Engine speed (rotational frequency)
at idling
Fuel consumption (in accordance with ISO8893) at max.
engine performance
IT PT NL SV DA NO FI HU CS RU
English

ATTACHING THE SHOULDER STRAP

Note: Always use the shoulder strap/harness with your
brushcutter.
RBC430SES
Follow these steps to attach the shoulder strap.
Connect the latch on the strap to the hanger bracket.
Q
Adjust the strap to a comfortable position.
Q
RBC430SBS
See Figure 4.
Follow these steps to attach the shoulder strap.
Connect the latch on the shoulder harness to the
Q
strap hanger.
Adjust the strap to a comfortable position.
Q
FEATURES
18 in / 457 mm
Triarc blade 8"(200mm)
Optimum: 65 cm³
3000-3600/min
23
RO PL SL HR ET
RBC430SES
30 cm³
2.4 & 2.7 mm
200 mm
5.90 kg
5.85 kg
350 cm³
Max: 125 cm³
0.70 kW
10000/min
12000/min
0.48 kg/h
LT LV SK BG
RBC430SBS
30 cm³
18 in / 457 mm
2.4 & 2.7 mm
200 mm
Triarc blade
8"(200mm)
6.40 kg
6.35 kg
350 cm³
Optimum: 65 cm³
Max: 125 cm³
0.70 kW
10000/min
12000/min
3000-3600/min
0.48 kg/h
