Kreg FOREMAN DB210-EUR Mode D'emploi page 11

60 mm
36
16
11 mm
34
13
Operation
Mitered Corners
Two pocket holes with our recommended minimum spacing of 14mm
center-to center fit entirely on the face of a 19mm-thick board at least
60mm wide. Simply set up the machine for 19mm-thick stock. Then
with the mitered end of the workpiece against the fence, drill one hole
11mm from the miter heel and a second hole 60mm from the miter toe.
You also can drill one pocket hole on each side of a miter joint rather
than drilling both holes on the same side.
Workpiece stops
ATTENTION
A workpiece stop can be used on either side of the
drill guide by sliding it out of the fence T-slot, flipping it over so
the open end of the stop arm faces center, and reinstalling it in
the T-slot.
Loosen the socket-head bolt on the workpiece stop (34) with the
3mm hex wrench (13), slide the stop to the desired location, and
tighten the bolt. Keeping the fence (16) centered side to side allows
you to use the center-reading measuring tape (36) to position the
stops. Override a stop by placing the workpiece over the stop,
pressing the spring-loaded stop arm into the stop body.
Each stop arm can be held in the retracted position by pressing the
arm into the stop body and then sliding it toward the socket-head bolt
that secures the stop in the fence. The notch in the arm provides a
grip point. To reactivate the stop arm, slide it away from the bolt.
10.
