Safety and installation instructions
NOTICE!
A
To prevent the risk of short circuits, always disconnect the negative
terminal of the vehicle's electrical system before working on it.
If the vehicle has an additional battery, its negative terminal should
also be disconnected.
WARNING!
!
Inadequate supply cable connections could result in short circuits,
which could have as a consequence that:
– Cable fires occur
– The airbag is triggered
– Electronic control devices are damaged
– Electric functions fail (indicators, brake light, horn, ignition,
lights)
Please observe the following instructions:
When working on the following cables, only use insulated cable lugs,
plugs and flat push-on receptacles:
– 30 (direct supply from positive battery terminal)
– 15 (connected positive terminal, behind the battery)
– 31 (return line from the battery, earth)
– L (indicator lights left)
– R (indicator lights right)
Do not use terminal strips.
Use a crimping tool to connect the cables.
When connecting to cable 31 (earth), screw the cable
– to the vehicle's earth bolt with a cable lug and a gear disc or
– to the sheet-metal bodywork with a cable lug and a self-tapping screw.
Ensure that there is a good earth connection.
If you disconnect the negative terminal of the battery, all data stored in the
volatile memories will be lost.
