Accessory Elastomer mounts VEN

8 Accessory Elastomer mounts VEN
RTN/4.7T/VEN (Elastomer mounts for Load cells RTN... / ≤4.7 t)
M8 x 20
(2)
M8 x 20
View Y
View Z
20
Scope of supply: Base plate, Elastomer, Centring plate
>4.7 t, Shims, Collapsible tube grease, Screws
∅80
RTN... / ≤4.7 t
∅70
108
130
3 Fixing pieces
A1153-2.0 HBM: public
( 1 )
"2 mm
Y
(3)
RTN... / ≤4.7 t
Material: Stainless steel; Elastomer =
Neoprene (chlorine butadiene rubber)
Deflection <0.8 mm (at 4.7 t)
(1) = Permissible play
(2) = 4 Screws M5x12 DIN EN ISO 4762;
Torque: 4 N@m
(3) = Bore hole for ventilation
(4) = Earthing connection
Dimensions in mm; 1 mm = 0.03937 inches
Z
(4)
Fixing with
bolts optionally
D10
∅25
h9
RTN
