5 Electrical installation
Standard devices in the power range 0.37 ... 11 kW
Mains connection: Fuses and cable cross−sections
Installation to UL
Supply conditions
Range
Fuses
Cables
Observe all national and regional regulations!
Operation at rated power
9300
Type
Operation without mains choke/mains filter
EVF9321−xV
EVF9322−xV
EVF9323−xV
EVF9325−xV
Operation with mains choke/mains filter
EVF9321−xV
EVF9322−xV
EVF9323−xV
EVF9324−xV
EVF9325−xV
EVF9326−xV
Max. connection cross−section of the terminal strip: AWG 12, with pin−end connector AWG 10
172
Description
l
Only in accordance with UL 248
l System short−circuit current up to 5000 A
l
System short−circuit current up to 50000 A
l
Only in accordance with UL
l
The cable cross−sections specified in the following apply under the following conditions:
– Conductor temperature < 60 °C
– Ambient temperature < 40 °C
Rated fuse current
Fuse
[A]
6
6
10
25
6
6
10
10
25
25
l
: All classes are permissible
rms
: Only classes "CC", "J", "T" or "R" permissible
rms
Cable cross−section
L1, L2, L3, PE
[AWG]
18
18
16
10
18
18
16
16
10
10
EDKVF9333V DE/EN/FR 7.2
