5.3.3 Oleopator-C-NST NS 65 to NS 100
Structure of the coalescence
element
The coalescence material is 100 mm
thick and consists of a porous polyure-
thane material fixed in special cassettes
which can be removed from the separator
for cleaning. There are 4 cassettes in
each separator. Table 2 lists the dimen-
sions of the coalescence elements.
Preparing for cleaning
Cleaning is made easier by first removing
the coalescence mat from the cassette so
that the mat can be cleaned on both sides
properly. First release the tensioners and
then remove the clamping device. The co-
alescence mat can then be removed from
the supporting basket.
5.3.4

Oleopator-PR-C-NST

Structure of the coalescence
element
The coalescence material consists of a
knitted wire mesh and is fixed to the sup-
porting basket at 2 or levels with 4 or 6
levels depending on the nominal size of
the separator.
Preparations for cleaning
Because the coalescence elements have
4 or 6 layers, it makes cleaning easier if
the outer layers are wound off the sup-
porting basket for cleaning. The two inner
layers can be left on the supporting bas-
ket for cleaning.
The three tensioners are first removed by
opening the Velcro fastener. The coales-
cence mat can then be removed from the
supporting basket.
Make sure that the sequence in which the
mats are removed is noted because each
layer has a different length.
Operating and maintenance instructions
Table 2. Dimensions of the coalescence element in the Oleopator C-NST NS 65 to
100 light liquid separators (the weights in the table refer to contaminated elements)
Separator nominal size
NS
65
80
100
Cleaning
Lay the coalescence mat onto a wire
mesh to allow the cleaning water to pass
through the mat and flow out on the lower
side.
Table 3. Dimensions of the coalescence element in the Oleopator-PR
Separator nominal size
NS
80
100
The weight of a dirty coalescence element
is approx. 260 kg. Oleopator-PR separa-
tors have 2 coalescence elements.
Cleaning
Lay the coalescence mat onto a wire
mesh to allow the cleaning water to pass
through the mat and flow out on the lower
side.
Assembling the coalescence mat
Assemble the coalescence mats by follow-
ing the procedure for removing the mats
from the supporting basket in reverse
order.
Dimensions
in mm
1360 x 540 x 100
1755 x 540 x 100
2050 x 540 x 100
Caution
The water used to wash the coalescence
mat must be treated in a light liquid
separator afterwards and must not be
discharged untreated into the sewers or
rivers.
Number of levels Number of mats per level
2
3
Caution
The water used to wash the coalescence
mat must be treated in a light liquid
separator afterwards and must not be
discharged untreated into the sewers or
rivers.
Weight
kg
70
90
110
Environmental
protection
4
8
Environmental
protection
