CARE AND MAINTENANCE OF YOUR STAND UP LIFT

REPLACING THE KNEE PAD

(FIGURE 4)
1. Remove the four (4) button screws and washers that
secure existing knee pad to the stand up lift.
2. Remove the existing knee pad from stand up lift.
C
3. Position the mounting holes in the new knee pad with
A
the mounting holes in the stand up lift.
R
4. Using the existing hardware, secure the new knee
E
pad to the stand up lift.
-
M
Knee Pad
A
I
N
T
E
N
A
N
C
Button Screws
E
FIGURE 4 - REPLACING THE KNEE PAD

REPLACING OPTIONAL LEG STRAP

(FIGURE 5)
1. Remove TOP (2) button screws and washers that
secure knee pad and existing leg strap to stand up lift.
2. Loosen BOTTOM two (2) button screws and wash-
ers that secure knee pad and existing leg strap to
stand up lift.
3. Remove the existing leg strap from stand up lift.
4. Position the new leg strap between the four (4) mount-
ing holes as shown in FIGURE 5.
NOTE: Make sure there is equal amounts of leg strap on
either side of the stand up lift.
Knee Pad
Leg Strap
Washer
FIGURE 5 - REPLACING OPTIONAL LEG STRAP
5. Position the mounting holes in the knee pad with the
6. Using the existing hardware, secure the knee pad and

REPLACING THE PADDED COVER

(FIGURE 6)
1. Pull fastening strips on the existing padded cover apart.
2. Remove the existing padded cover from the lift arm.
3. Position the new padded cover around the lift arm.
4. Secure fastening strips on the new padded cover
Stand Up Lift
Washers

REPLACING ELECTRIC ACTUATOR

(FIGURE 7)
1. Remove the bottom nut, washer and shoulder bolt
2. Rest the lift arm on your shoulder and remove the top
3. Remove the electric actuator.
4. Reverse STEPS 1-3 for installation of the new electric
DO NOT overtighten mounting hardware. This will
Stand Up
damage mounting brackets.
Lift
Button Screw
18
mounting holes in the stand up lift.
new leg strap to the stand up lift.
together.
Padded Cover
FIGURE 6 - REPLACING THE PADDED COVER
that secure the electric actuator to the mast mounting
bracket.
nut, bolt, bracket and bushing from the lift atm mount-
ing bracket.
actuator.
CAUTION
Fastening Strips
Lift Arm
