Code Possible settings
No. Name Lenze
C0002* Transferring
s
parameter sets
with the keypad
uSEr
(Contin.)
C0002* Saving your own
s
basic setting
uSEr
(Contin.)
C0002* Loading/copying
s
the own basic
setting
uSEr
(Contin.)
EDK82MV752 DE/EN/FR 7.2
Selection
Keypad ð PAR1 (+ FPAR1)
71 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
11 with all other function modules
Keypad ð PAR2 (+ FPAR1)
72 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
12 with all other function modules
Keypad ð PAR3 (+ FPAR1)
73 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
13 with all other function modules
Keypad ð PAR4 (+ FPAR1)
74 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
14 with all other function modules
Controller ð keypad
80 with function module application I/O,
INTERBUS, PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
20 with all other function modules
Keypad ð function module
40 only with function module INTERBUS,
PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
Function module ð keypad
50 only with function module INTERBUS,
PROFIBUS−DP, LECOM−B,
DeviceNet/CANopen
PAR1 ð own basic setting
9
own basic setting ð PAR1
5
own basic setting ð PAR2
6
own basic setting ð PAR3
7
own basic setting ð PAR4
8
l
Commissioning
Important controller codes
IMPORTANT
Overwrite selected parameter set
and, if required FPAR1, with the
corresponding data of the keypad
Copy all available parameter sets
(PAR1 ... PAR4, if required FPAR1) into
the keypad
Only overwrite the module−specific
parameter set FPAR1 with the data of
the keypad
Only copy the module−specific
parameter set FPAR1 into the keypad
For the parameters of the controller
you can save an own basic setting
(e.g. the delivery status of your
machine):
1. Ensure that parameter set 1 is
active
2. Inhibit controller
3. Set C0003 = 3, confirm with v
4. Set C0002 = 9, confirm with v,
the own basic setting is saved
5. Set C0003 = 1, confirm with v
6. Enable the controller
By using this function you can also
just copy PAR1 into the parameter
sets PAR2 ... PAR4
Restore own basic setting in the
parameter set selected
6
