DGPI(L)−...−AI F
Pneumatic linear drive DGPI(L)−
1

Operating parts and connections

aB
aC
aA
1
Compressed air port indirect
2
Compressed air port direct
3
Lubricating nipple for roller bearing
4
Groove for fastening the work load
5
Slide
6
Hole for fastening the work load
7
Thread for fastening the work load
Fig. 1
Festo DGPI(L)−...−AIF 0409a English
1 2
aJ
−AIFEnglish
3 4 5
9
8
Driver
9
Hole for earth connection
aJ
Measuring system connection
aA
Thread for fastening the drive
aB
Adjusting screw for end position cushioning
aC
Compressed air port on variant ...−D2
6
8 7
