Lifetime SPEED SHIFT Instructions De Montage

SPEED SHIFT
BASKETBALL SYSTEM
MODEL 90000
BEFORE ASSEMBLY:
• Decide with what to fi ll the base
(sand is recommended).
• At least 2 adults recommended for setup.
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
TOOLS REQUIRED
7/16" (≈11mm), 1/2" (≈13mm),
9/16" (≈14mm), 3/4" (≈19mm)
(2)
(1)
(1)
QUESTIONS?
CONTACT LIFETIME CUSTOMER SERVICE:
Dial 1-800-225-3865
™
(1)
(1)
(1)
Live Chat:
www.lifetime.com/customerservice/home
(Click on the "LIVE CHAT" tab)
ASSEMBLY INSTRUCTIONS
Pour le français, voir la page 2. Para el español, ver la página 3.
3/16" (≈5mm)
(2, included)
(1)
375 lb (≈170kg)
For Customer Service in Mainland
Europe and the United Kingdom,
E-mail: csinternational@lifetime.com
TABLE OF CONTENTS
Icon legend....................................4
Warnings & notices........................5
Pole assembly................................6
Pole-to-base assembly.................10
Backboard-to-rim assembly.........15
Backboard-to-pole assembly........21
Parts identifi er.............................i–iv
Handle assembly..........................24
Final assembly.............................33
Maintenance..............................38
Warning sticker............................39
Registration........................40
Warranty................................41
Model Number: 90000
Product ID:
