 SECTION 3 (CONTINUED) / SECTION 3 (SUITE) / SECCIÓN 3 (CONTINUACIÓN)
TOOLS AND HARDWARE REQUIRED / OUTILS ET QUINCAILLERIE REQUIS / INSTRUMENTAL Y HERRAJE REQUERIDOS
7/16 in/po (≈11 mm) (x2)
ABS (x2)
3.1
• Slide the U-bolt (BNP) through the left and right
backboard brackets (AJJ & AJK). The U-bolt must rest
in the notches of the backboard brackets.
• Faire glisser le boulon en « U » (BNP) à travers les
supports du panneau gauche et droit (AJJ et AJK). Le
boulon en « U » doit rester dans les encoches
des supports du panneau.
• Deslizar el perno en «U» (BNP) por los soportes del
tablero izquierdo y derecho (AJJ y AJK). El perno en
«U» debe dejar en las muescas de los soportes
del tablero.
AJJ
BNP
AJK
Notch / Encoche / Muesca
AAS (x2)
AAB (x2)
3.2
• Secure the left and right backboard brackets (AJJ & AJK)
with the hardware indicated.
• Attacher les supports du panneau droit et gauche (AJJ et AJK)
à l'aide de la quincaillerie indiquée.
• Sujetar los soportes del tablero derecho e izquierdo (AJJ y
AJK) usando el herraje indicado.
16
BNP (x1)
AAS
ABS
AAB
AAB
AAS
ABS
