4.9. Installing the backrests and headrests
The frame for the heater is assembled on the back side (pre-drilled) with four
3.5 x 50 mm screws. If this is not possible, fasten with the screws from the
front (see image on right).
Screw the Multiclips tight with the aid of the mounting template using the
eight 3.5 x 35 mm screws.
Fig. 29: Installing the backrests
EN
Finally, insert the backrests from above down onto the brackets until they latch.
