Instructions for installation and use
Fig. 23: Inserting the IR heat panel
Pay attention to the switch cables when inserting the IR heat panel,
and ensure that they are not pinched or damaged.
Insert the IR heat panel into the U-rails. The recess provides the duct for the front
heater cable.
4.6. Installing the LED strip
Fig. 24: Attaching the LED strip
3 screws: 3.5 x 50 mm
Screw the LED cover strip tight from above (pre-drilled)
p. 23/36
EN
