Instructions for installation and use
Installing the roof elements
Check the right angle before screwing the wall elements together.
Observe the tip on Page 8.
Fig. 11: Installing the roof support slats
Screw the roof support slats tight on all cabin walls as shown in Fig. 11. When doing
this, ensure that the wall elements form a flush edge with the roof support slats.
16 screws: 3.5 x 50 mm
Fig. 12: Roof support slats
Position of slat with drill hole
