2.1.2 Overview presentation
The charger / converters are divided into 2 zones:
The user interface zone
The connexion zone
User interface area
2.2
Push buttons.
Boost and/or Refresh
indicator
Connexion area
2.3
Bolts
1 2 3 4 Dip Switches
for CANBUS address
Battery type indicator
2 CANBUS connectors
(not provided)
OTD and temperature
probe (not provided)
ON indicator
Alarm indicator
Charging phase
indicator
5
