Part Number
Model
Recommended battery bank *
Input
Voltage
Maximum current
Nominal Power
Efficiency
No load current consumption
Standby current consumption
Input fuses
Output
Number of battery bank
rated current
Charging curve
Battery type
Boost voltage (default)
Floating voltage (default)
Regulation tolerance
Peak to peak ripple and noise
Automotive fuse
Environment
Cooling
Operating temperature
Storage temperature
Relative humidity
Casing
Length, height, depth / Weight
Fixing center distance
Fixing screw (wall)
Protection factor
PCB protection
Standards
CE declaration of conformity
CE / EMC
CE / Security - Others
Protections
* Battery capacity recommended for lead type batteries, ratio C/10. Consult us for lithium batteries.
DC36-12/40PL
DC36-24/30PL
36-12V/40A
36-24V/30A
300-500Ah
200-400Ah
30V -48V
30V -48V
20A
600W
2 x 20A /80V
2 x 20A /80V
40A
IU or IUoU through internal push-button or CAN-BUS (Boost, Absorption,
Floating and Refresh – factory setting)
Gel, AGM, calcium lead, lithium, stabilized power supply, etc.
Other choices through internal setting:
14.4VDC
13.8VDC
2 x 25A /32V
2 x 25A /32V
From -20°C to +60°C, derating above 60°C.
Above 65°C, current limitation
up to 70% (95% without condensation)
Water-repellent varnish (marine environment)
EN60335-2-29. Pending E-marking.
Polarity reversal, short-circuit, abnormal overheating
DC36-36/20PL
36-36V/20A
150-250Ah
30V -64V
25A
25A
900W
900W
96% typical
< 90 mA
< 12 mA
2 x 20A /80V
1
30A
20A
28.8VDC
43,2VDC
27.6VDC
41,4VDC
< 2% (at rated conditions)
< 2% (at rated conditions)
2 x 20A /80V
Natural (fanless)
From -40°C to +70°C
236 x 180 x 80 mm / 2kg
219 x 155 mm
4 x M5 round head screws
IP22
Available on request
EN61204-3
DC36-48/15PL
36-48V/15A
100-200Ah
30V -64V
25A
900W
2 x 20A /80V
15A
57.6VDC
52.2VDC
1 x 20A /80V
23
