Indicators
3.8
Led
charging
LED "ON"
default
LED
default
ALARM
Boost
LEDS
OPTIONS
Refresh
AGM-GEL...
LEDS
Wet lead
BATTERY
Lithium
SELECOR
Custom
LEDS
CHARGE
-
STATUS
The following LED indicators are visible on the front of the appliance to show the status of the charger.
When the charger saves a new configuration, the status LEDs light up one after the other to indicate that the
configuration has been saved.
LED
Mode
status
(flash)
(off)
(flash)
(flash)
(flash)
(off)
Charger status
Charger is ON
Startup voltage not reached
No or poor-quality DC current
Input fuse is blown
Internal charger malfunction
Other faults
Boost activated
Refresh activated
Battery type: AGM/Gel/ Sealed Lead
Battery type: Wet lead
Battery type: Lithium
Custom mode
Charger in BOOST phase
Charger in ABSORPTION phase
Charger in FLOATING phase
Charger in REFRESH phase
Output voltage OFF
OTD fault
Output fuse blown
temperature range
No output voltage
19
