Part Number
Model
Recommended battery bank *
Input
Voltage
Maximum current
Nominal Power
Efficiency
No load current consumption
Standby current consumption
Input fuses
Output
Number of battery bank
rated current
Charging curve
Battery type
Boost voltage (default)
Floating voltage (default)
Regulation tolerance
Peak to peak ripple and
noise
Automotive fuse
Environment
Cooling
Operating temperature
Storage temperature
Relative humidity
Casing
Length, height, depth) /
Weight
Fixing center distance
Fixing screw (wall)
Protection factor
PCB protection
Standards
CE declaration of conformity
CE / EMC
CE / Security - Others
Protections
* Battery capacity recommended for lead type batteries, ratio C/10. Consult us for lithium batteries.
DC48-12/40PL DC48-24/30PL DC48-36/20PL DC48-48/15PL
48-12V/40A
48-24V/30A
300-500Ah
200-400Ah
40V-64V
40V-64V
15A
20A
900W
600W
1 x 20A /80V
1 x 20A /80V
40A
30A
IU or IUoU through internal push-button or CAN-BUS (Boost, Absorption, Floating
Gel, AGM, calcium lead, lithium, stabilized power supply, etc.
Other choices through internal setting:
14.4VDC
28.8VDC
13.8VDC
27.6VDC
2 x 25A /32V
2 x 25A /32V
From -20°C to +60°C, derating from 60°C. Above 65°Cswitch off
up to 70% (95% without condensation)
Water-repellent varnish (marine environment)
Polarity reversal, short-circuit, abnormal overheating
48-36V/20A
150-250Ah
40V-64V
20A
900W
96% typical
< 90 mA
< 12 mA
1 x 20A /80V
1
20A
and Refresh – factory setting)
43,2VDC
41,4VDC
< 2% (at rated conditions)
< 2% (at rated conditions)
2 x 20A /80V
Natural (fanless)
From -40°C to +70°C
236 x 180 x 80 mm / 2kg
219 x 155 mm
4 x M5 round head screws
IP22
Available on request
EN61204-3
EN60335-2-29. Pending E-marking.
DC48-48/30PL
48-48V/15A
48-48V/30A
100-200Ah
200-400Ah
40V-64V
40V-64V
20A
30A
900W
1800W
1 x 20A /80V
2 x 20A /80V
15A
30A
57.6VDC
57.6VDC
52.2VDC
52.2VDC
1 x 20A /80V
2 x 20A /80V
24
