3.4.4.4 Input startup voltage
The Charger won't start until you reach this value.
Input start-up
Input start-up
voltage for 12V
voltage for 24V
input voltage
input voltage
10V
10.4V
10.8V
11.2V
11.6V
12V
12.4V
12.8V
13.2V
13.6V
14V
To avoid untimely stops in the event of voltage variations, to stop the product, subtract the values in the table
below from the starting voltage:
In example starting voltage @13,2v -> input stop voltage= 13.2v-0.5v=12.7v
3.4.4.5 Output current limitation
You can set a percentage of the rated current, by default 100% = full power
Output current limitation
10%
20%
30%
40%
50%
3.4.4.6 Select temperature probe for alternator
This function enables to protect the alternator from excessively high temperatures. Over a programmable
temperature threshold, the output current decreases. See options and features.
Setting
0
1
2
3
4
5
Input start-up
voltage for 36V
input voltage
20V
20.8V
31.2V
21.6V
32.4V
22.4V
33.6V
23.2V
34.8V
24V
24.8V
37.2V
25.6V
38.4V
26.4V
39.6V
27.2V
40.8V
28V
100%
Maximum external probe temperature
Disable
70°C
80°C
90°C
100°C
110°C
Input start-up
voltage for 48V
input voltage
30V
40V
41.6V
43.2V
44.8V
46.4V
36V
48V
49.6V
51.2V
52.8V
54.4V
42V
56V
60%
70%
80%
90%
0.5V (for 12V input)
1.0V (for 24V input)
1.5V (for 36V input)
2.0V (for 48V input)
1 V
