INSTALL THE STAINLESS OR CUSTOM WOOD DOOR PANEL
1. Attach the Door Panel to the Top Adjustment Bracket with
the 4 screws, B or C.
2. Attach the Door Panel to the bottom of the door with the
4 screws, B or C and washers D.
Note: Don't tighten the bottom screws to facilitate
adjusting the panel later.
49-1000777 Rev. 2
Installation Instructions
3. If there are wrinkles or folds in the gasket between the
door panel and glass, move a thin plastic card along the
edge between the soft edge of the gasket and the glass
to smooth wrinkles and align gasket. (Figure 3)
Figure 3
CAUTION
If you need to switch door panels,
the top screw to prevent from breaking bottom door
panel mounting brackets.
Front of door
27
