USING THE BEVERAGE CENTER
FULL EXTENSION DRAWERS
All of the full extension drawers pull out so bottles can be
conveniently added or removed.
Any of the full extension drawers can be removed to store
larger bottles.
To remove:
1. Pull the full extension drawer out to the STOP position.
2. Push the tab on right drawer guide down while pulling
the tab on left guide up, and pull the drawer out.
To replace:
1. Push the drawer slide arm back into the unit.
2. Pull the small slide sub-assembly completely forward.
3. Insert the sides of the drawer back into the guides.
4. Push until the tabs lock into place.
Appearance may vary
Sub-assembly
NOTE: Make sure the tabs on the full extension drawer
guides are fully engaged before loading any bottles. Pull
the drawers out all the way to the STOP position and
push back in several times to make sure locking tabs are
properly engaged.
16
Tab (push tab down
on right drawer
guide, pull tab up on
left drawer guide)
To replace, push drawer
slide arm back into unit
Sub-assembly
Pull small slide sub-
assembly completely
forward
Soft closure
This product is designed with a soft closing door system.
softens the closing force of the door. As the door nears
closure a dampening mechanism is engaged to soften
the impact. This hinge system is designed to keep the
door open until it reaches the dampening, self closing
mechanism.
49-1000777 Rev. 2
