REMOVE PACKAGING
• Remove tape and glue residue from surfaces before
turning on the beverage center. Rub a small amount
of liquid dish soap over the adhesive with your fingers.
Wipe with warm water and dry.
NOTE: Do not use sharp instruments, rubbing alcohol,
flammable fluids, or abrasive cleaners to remove
tape or glue. These products can damage the surface
of your beverage center. For more information, see
• Dispose of/recycle all packaging materials.
REVERSING THE DOOR SWING
1. Open the door, insert the flat head screw driver into
the notch on the side of the rectangular plastic cover at
the opposite side of the hinge to remove both top and
bottom covers.
At hinge side, insert flat head screw driver under the T
shape hinge cover to pop the cover off for both top and
bottom hinge. Remove the square cover next to them
with same screw driver.
Insert screw driver from
this side to pop the square
cover open.
2. Completely
loosen the
screw to
detach the
door from
cabinet.
3. Remove the
door and leave the hinges open.
49-1000777 Rev. 2
Installation Instructions
Insert screw driver under
T shape hinge cover.
Screws
WARNING
Small objects are a choke hazard for
children. Remove and discard any parts not used.
CLEAN BEFORE USING
After you remove all of the packaging materials, clean
the inside of the beverage center before using it. See the
cleaning instructions in "Care and Clean".
4. Remove hinge screws form cabinet and install them on
the opposite side. Recommend to screw halfway in for
the top two screws so that you can slide the hinge on
them to have some support during the installation.
5. If the door has top trim installed, then remove the top
plastic trim from door by insert a flat head screw driver
to slots under the trim (suggest to start from handle
side) and pop it open. Otherwise go to next step.
6. Remove hinges from door. Move the trim support
bracket from left side top of the door to right side top of
the door. Place hinges on the other side with top hinge
at bottom and bottom hinge at top.
There is a washer on the bottom hinge. When you
move the bottom hinge to the other side as top hinge,
be sure you remove the washer and place it on the
new bottom hinge, which
is the original top hinge
on the other side.
Screws
Slots
Trim
support
bracket
21
