REVERSING THE DOOR SWING
7. Install square covers from step 1 to the new hinge
location at top and bottom of cabinet. Install the
rectangular cover from step 1 to the new non hinge
side at top and bottom of the front cabinet.
8. Slide the top hinge to top 2
screws on the cabinet. Install
the bottom hinge screw,
do not tighten them. Level
the door then tighten all 4
screws. Install the T shape
hinge cover from step 2 to
the cabinet.
9. If your product does not have top plastic trim installed,
you can find it inside of unit on the top shelf. Separate
the end cover block from top trim by inserting the flat
head screw driver in the slot under the trim at the end
of trim.
Place it on the other side of the trim. The trim is ready
to be installed.
Slot
22
Installation Instructions
(CONT.)
Square
covers
10. Perform this step only after you complete the door
panel installation and adjustment. Press the spring
strip in while you install the trim on top of the door.
Press down the trim to engage the clip of the trim to
the brackets on the door.
Brackets for trim
Spring strip
49-1000777 Rev. 2
