9.2.11 Dimensions de FA08
182
(7.2)
336
(13.2)
128
(5)
Illustration 22: Dimensions de FA08
94 | Danfoss A/S © 2024.07
205
(8.1)
127
255
50 (5)
(10)
(2)
58
(2.3)
368
(14.5)
743
680
(29.3)
(26.8)
721
(28.4)
259
(10.2)
60
(2.4)
38
(1.5)
308
(12.1)
12
(0.47)
27.5
12
(1.08)
(0.47)
Ø 16
(0.63)
200
(7.9)
A
997
(39.3)
B
255
(10)
Dimensions extérieures et des bornes
27.5
(1.08)
Ø 10
(0.39)
(0.39)
10
(0.39)
AJ319739940640fr-000501 / 136R0269
Ø 10
