Manuel de configuration | Variateurs de fréquence iC7-Automation
9.3.3 Dimensions de FK08
208.5
(8.2)
116
(4.6)
571
(22.5)
Illustration 33: Dimensions de FK08
Danfoss A/S © 2024.07
336 (13.2)
304 (11.9)
133.5
(5.2)
244(9.6)
58.5 (2.3)
275 (10.8)
367 (14.4)
197
(7.7)
Dimensions extérieures et des bornes
12
(0.47)
L1/L2/L3
X0
X1/X2
-DC, R-, +DC/R+
U/V/W
12
(0.47)
25
(0.98)
A
743
(29.3)
955
721
(37.6)
(28.4)
B
10 (0.39)
AJ319739940640fr-000501 / 136R0269 |
33.5
(1.31)
Ø10
(0.39)
Ø16
(0.63)
200
(7.9)
267 (10.6)
33.5
(1.31)
Ø10
(0.39)
