To start a warm engine:
1. Set the ignition switch to the "I" (ON) position.
2. Press the primer bulb 10 times.
3. Set the choke lever to "RUN" position.
4. Pull the starter grip until the engine starts. Do not pull
the starter grip more than 4 times.
To stop the engine:
Release the trigger. Push the On/Off switch to the "O"
(OFF) position.
DESCRIPTION
1. Pro Cut string head
2. String head/shaft/grass deflector assembly
3. Silencer
4. Starter grip and rope
5. Choke lever
6. On/off switch
7. Throttle trigger
8. Handlebar
9. Line carrier
10. Primer bulb
11. Air filter cover
12. Fuel cap
13. Grass deflector
14. Mow ball
15. Button
16. Guide recess
17. Knob
18. Lower handlebar
19. Upper handlebar
20. Frame opening
21. Bolt
22. Throttle cable
23. Holes
24. Clip
25. Bolt
26. String line
27. Line exit holes
28. Line load holes
29. Top cap
30. Open area
31. Full choke position
32. Run position
33. Air intake area
34. Air filter cover screw
35. Air filter base
36. Air filter element
37. Spark plug
38. Spark plug cover
39. Line length cutter
40. Blocking bar
PT NL SV DA NO FI
English (Original instructions)
HU CS RU RO PL SL
KNOW YOUR TOOL
The safe use of the product requires an understanding of
the information on the tool and in this operator's manual
as well as a knowledge of the project you are attempting.
Before use of this product, familiarize yourself with all
operating features and safety rules.
GRASS DEFLECTOR
ASSEMBLY
UNPACKING
This product requires assembly.
Carefully remove the product and any accessories
from the box. Make sure that all items listed in the
packing list are included.
Packing list
Trimmer power head/wheel assembly
Pro Cut string head/shaft/grass deflector assembly
Handle assembly
Hardware bag
Operator's manual
Figure sheet
Bottle of 2 stroke oil
2.7 mm lines (18 pcs)
Line carrier
Knob (4 pcs)
Bolt (4 pcs)
Clip (2 pcs)
NOTE: Be careful not to bend the throttle cable when
unpacking.
Do not use this product if any parts on the packing list are
already assembled to your product when you unpack it.
Parts on this list are not assembled to the product by
the manufacturer and require customer installation. Use
of a product that may have been improperly assembled
could result in serious personal injury.
Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product.
If any parts are damaged or missing, please call
14
HR ET LT LV SK BG
WARNING
