HYGRASGARD
PRESENCE BUTTON
The presence button is mapped via registers 1x0001 to 1x0003. If the button is not asSigned any LED
(LED mode is not equal to a value of 5) the button states can be recorded via the following register:
1x0001 Button pressed = 1, detection via edge change
1x0002 Button released = 1, detection via edge change
1x0003 Button status, current button status at time of query
The button information that is triggered by an edge change can be saved until the next MODBUS telegram query
"Function 02 Read Discrete Input" in order to enable the reliable detection of button activation even with longer bus sampling
cycles (e.g. 1 second).
When assigning the button to a LED (LED mode contains a value of 5), the LED status will change automatically every time
a button is pressed. The corresponding LED must be switched on via the function 05 Write Single Coil.
The LED status can be queried via register 1x0001.
The register 1x0002 has no function.
The register 1x0003 shows the current button status at the time of query.
The LED status can also be set or deleted via the function 05 Write Single Coil Bit 6.
TELEGRAMS
Function 02 Read Discrete Input
Register Parameter
1x0001 Presence button /
LED status
1x0002 Presence button
1x0003 Presence button
Note: The addresses 1x0004...1x0008 are read with the value "0".
Function 04 Read Input Register
Register Parameter
3x0001 Temperature
3x0002 Temperature
3x0003 Relative humidity
3x0004 Relative humidity
3x0005 Setpoint potentiometer
3x0006 Dew point
3x0007 Absolute humidity
3x0008 Mixture ratio
3x0009 Enthalpy
3x0010 Rotary switch
®
RFTF - Modbus | Configuration, Telegrams
pressed /
set
released
current
Sampling 4 s
Filtering 32 s
Sampling 4 s
Filtering 32 s
Computed value
Computed value
Computed value
Computed value
Data Type
Bit 0
Bit 1
Bit 2
Data Type
Signed 16 Bit
320...1220
Signed 16 Bit
320...1220
Signed 16 Bit
Signed 16 Bit
Signed 16 Bit
Signed 16 Bit
320...1220
Signed 16 Bit
Signed 16 Bit
Signed 16 Bit
Unsigned 8 Bit
25
Value Range
0 / 1 OFF - ON
0 / 1 OFF - ON
0 / 1 OFF - ON
Value Range
0... 500 0.0... +50.0 °C
+32.0...+122.0 °F
0... 500 0.0... +50.0 °C
+32.0...+122.0 °F
0...1000 0.0...100.0 % RH
0...1000 0.0...100.0 % RH
0...1000 0.0...100.0 %
0... 500 0.0... +50.0 °C
+32.0...+122.0 °F
0...800 0.0...80.0 g / m³
0...349 0.0...34.9 gr / ft³
0... 800 0.0... 80.0 g / kg
0...5600 0.0...560.0 gr / lb
0...850 0.0...85.0 kJ / kg
0...360 0.0...36.0 Btu / lb
0...4 Positions 1...5
