S+S Regeltechnik HYGRASGARD RFTF-Modbus Notice D'instruction page 20

G U
HYGRASGARD
Switchable system of units
Measurements / Data points
Temperature
Relative humidity
Dew point
Absolute humidity
Mixture ratio
Enthalpy
Type ⁄ WG01
RFTF - Modbus
R F T F - M o d b u s
R F T F - M o d b u s LCD
RFTF - Modbus - xx
R F T F - M o d b u s P
R F T F - M o d b u s P LCD
R F T F - M o d b u s P 5L
R F T F - M o d b u s P 5L LCD
R F T F - M o d b u s P D5
R F T F - M o d b u s P D5 5L
R F T F - M o d b u s P T D5 5L
R F T F - M o d b u s P T
R F T F - M o d b u s P T LCD
R F T F - M o d b u s P T 5L
R F T F - M o d b u s P T 5L LCD
Equipment:
Note:
ACCESSORIES
KA2 -Modbus Communication adapter (with USB and RS485 interface)
for system connection (incl. quick-start software)
LA -Modbus Line termination device (with terminating resistor)
as an active bus termination of RS485 networks
®
RFTF - Modbus
SI (default) → Imperial
[°C] → [°F]
[% RH] → [% RH]
[°C] → [°F]
[g/m³] → [gr/ft³]
[g/kg] → [gr/lb]
[kJ / kg] → [Btu/lb]
Measuring Range ⁄ Readout
Humidity (switchable)
0...100 % RH (default)
0...80 g ⁄ kg (MV)
0...80 g ⁄ m 3 (a.F.)
0...85 kJ ⁄ kg (ENT.)
–20...+80 °C (TP)
(as above)
0...100 % RH (default)
0...80 g ⁄ kg (MV)
0...80 g ⁄ m 3 (a.F.)
0...85 kJ ⁄ kg (ENT.)
–20...+80 °C (TP)
(as above)
(as above)
(as above)
(as above)
(as above)
(as above)
(as above)
(as above)
(as above)
(as above)
P = Potentiometer (setpoint setter)
T = Presence push-buttons
System of units SI (default) or imperial (can be changed via Modbus).
Measuring ranges
Output
Temperature
0...+50 °C Modbus
+32... +122 °F
(as above) Modbus
0...+50 °C Modbus
+32... +122 °F
(as above) Modbus
(as above) Modbus
(as above) Modbus
(as above) Modbus
(as above) Modbus
(as above) Modbus
(as above) Modbus
(as above) Modbus
(as above) Modbus
(as above) Modbus
D5 = Rotary switch, 5-step
5L = LED display, multi-colour (5x)
20
Rev. Data - V25
SI (default) →
0...+50 °C → – 32...+ 122 °F
0...100 % RH → 0...100 % RH
0...+50 °C → – 32...+ 122 °F
0...80 g/m³ → 0...35 gr/ft³
0...80 g/kg → 0...560 gr/lb
0...85 kJ / kg → 0...36 Btu/lb
Item No.
Display
1201-42B 6- 6000-000
■ 1201- 42B6- 7000-000
1201-42B 6- 6001-005
■ 1201-42B6- 7001-005
1201-42B6- 6119-005
■ 1201- 42B6-7119- 005
1201-42B6- 6012-841
1201-42B6- 6120-841
1201-42B6- 6121-841
1201-42B6- 6047-005
■ 1201- 42B6- 7047- 005
1201-42B6- 6051-005
■ 1201-42B6-7051-005
1906- 1200- 0000- 100
1906- 1300- 0000- 100
Imperial
