HYGRASGARD
Function 06 Write Single Register & Function 16 Write Multiple Register
Register Parameter (LEDs)
4x0013 Bar graph value (LED)
4x0014 Bar graph mode
Bar graph mode
(Value)
4x0015 LED 1 mode
4x0016 LED 2 mode
4x0017 LED 3 mode
4x0018 LED 4 mode
4x0019 LED 5 mode
LED s mode
(Value)
4x0020 LED 1 colour
4x0021 LED 2 colour
4x0022 LED 3 colour
4x0023 LED 4 colour
4x0024 LED 5 colour
LED s colour
(Value)
Continued on next page!
®
RFTF - Modbus | Telegrams
LEDs can be controlled independently
Green - Green - Yellow - Yellow - Red
A
(LED traffic lights)
Green - Yellow - Red
B
(all LEDS in the same colour)
Blue - Red-blue - Red
C
(all LEDS in the same colour)
Colour from LED colour register (see 4x0025)
D
Continuous light
Brief flash
Medium flash
Long flash
Quick flash
Change with button
White
Yellow
Orange
Red
Yellow-green
Green
Turquoise
Blue
Violet
Colour from LED colour register (see 4x0025)
Data Type
Unsigned 16 Bit
Unsigned 8 Bit
Unsigned 8 Bit
Unsigned 8 Bit
Unsigned 8 Bit
Unsigned 8 Bit
Unsigned 8 Bit
Unsigned 8 Bit
Unsigned 8 Bit
Unsigned 8 Bit
Unsigned 8 Bit
Unsigned 8 Bit
27
Value Range
0...1000 0...100.0 %
0...4 Default = 0
0 Default setting
1
2
3
4
0...5 Default = 0
0...5 Default = 0
0...5 Default = 0
0...5 Default = 0
0...5 Default = 0
0 Default setting
1
2
3
4
5
0...100 Default = 0
0...100 Default = 0
0...100 Default = 0
0...100 Default = 0
0...100 Default = 0
dark = 0
0...9
light = 9
dark = 10
10...19
light = 19
dark = 20
20...29
light = 29
dark = 30
30...39
light = 39
dark = 40
40...49
light = 49
dark = 50
50...59
light = 59
dark = 60
60...69
light = 69
dark = 70
70...79
light = 79
dark = 80
80...89
light = 89
100
