HYGRASGARD
Function 05 Write Single Coil
Register Parameter
0x0001 Multi-coloured LED 1
0x0002 Multi-coloured LED 2
0x0003 Multi-coloured LED 3
0x0004 Multi-coloured LED 5
0x0005 Multi-coloured LED 6
0x0006 Set / Clear
LED button status
0x0007 Brightness LCD-backlighting
0x0008 System of units
Temperature
Relative humidity
Dew point
Absolute humidity
Mixing ratio
Enthalpy
Function 06 Write Single Register & Function 16 Write Multiple Register
Register Parameter (Display)
4x0001 Physical parameter displayed*
Standard display (cyclic):
Temperature,
Relative humidity
Alternative display (static):
Temperature
Setpoint potentiometer
Dew point
Relative humidity
Absolute humidity
Mixture ratio
Enthalpy
Freely configurable display
4x0002 7-Segment Value
4x0003 14-Segment Pattern 1
4x0004 14-Segment Pattern 2
4x0005 Segment Pattern
4x0006 Dot Matrix Character A
4x0007 Dot Matrix Character B
4x0008 Dot Matrix Character C
4x0009 Dot Matrix Character D
4x0010 Dot Matrix Character E
4x0011 Dot Matrix Character F
4x0012 Dot Matrix Character G
4x0040 Brightness LCD-backlighting
* The display value depends on the set unit system (see table "Function 05 Write Single Coil").
®
RFTF - Modbus | Telegrams
SI → Imperial
[°C] → [°F]
[%RH] → [%RH]
[°C] → [°F]
[g/m 3 ] → [gr/ft
[g/kg] → [gr/ lb]
[kJ/kg] → [Btu/lb]
Index on display
Data Type
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
3 ]
Data Type
Unsigned 8 Bit
–
1
2
3
4
5
6
7
–
Signed 16 Bit
Unsigned 16 Bit
Unsigned 16 Bit
Unsigned 16 Bit
Unsigned 8 Bit
Unsigned 8 Bit
Unsigned 8 Bit
Unsigned 8 Bit
Unsigned 8 Bit
Unsigned 8 Bit
Unsigned 8 Bit
Unsigned 8 Bit
26
Value Range
0 / 1 OFF - ON
0 / 1 OFF - ON
0 / 1 OFF - ON
0 / 1 OFF - ON
0 / 1 OFF - ON
0 / 1 CLEAR - SET
0 / 1 OFF - ON
0 / 1 SI (Default) -
Imperial
Value Range
0...10 0...10
Default
0
setting
1
2
3
4
5
6
7
10
–999...9999 –999...9999
see Binary Pattern
see Binary Pattern
see Binary Pattern
0...255 ASCII character
0...255 ASCII character
0...255 ASCII character
0...255 ASCII character
0...255 ASCII character
0...255 ASCII character
0...255 ASCII character
0...63 0...100%
