7.4.6 Menu
The following parameters can be set via the menu:
• Switching times (t1 – t9) for switching channels "Timer1" and "Timer2"
• Interval point in time and interval duration (Int)
• Additional Pump Running Time (Pu)
1. Press the Menu key to scroll through the menu.
- The system returns to the main screen after you have scrolled through the
menu and displayed last menu item.
2. After 60 seconds, the display automatically switches back to the main screen.
Menu
Fig. 7-13: Navigation structure menu
A: Programmable switching times
Per switching output ("Timer1" and "Timer2"), 9 memory blocks are available. The
switching outputs "Timer1" and "Timer2" can store the following data:
• Start time
• End time
• Start weekday
• End weekday
• Switching channel "Timer1" active/inactive
• Switching channel "Timer2" active/inactive
