5.3.5 Fitting the cable clamp
1. Fix the cable at the rear of the controller module using the cable clamp (A). If
room temperature controllers with a wired connection are used, first make the
electrical connection of the room temperature controllers and then fit the cable
clamp.
Fig. 5-16: Fitting the cable clamp
Fig. 5-17: Releasing the cable clamp
Mounting
RoCon UFH
2. Repeat this procedure for all other
cables.
3. It is possible to open the cable
clamps. To do so, pull the two tabs (B)
outwards and remove the cable
clamp.
