5.6
Inserting the timer module into the base module
ELECTROSTATIC DISCHARGE
•
Always earth yourself before touching electronic components.
•
Do not touch the product to plug it in; use the anti-electrostatic film to plug
the product into the slot.
Failure to follow these instructions can result in equipment damage.
Fig. 5-20: Inserting the timer module
Mounting
RoCon UFH
NOTICE
1. Remove the cover from the base
module.
2. Plug the product into the slot of the
base module.
EN
35
