HANDLEBAR ADJUSTMENT (Fig. 12)
good standard operating procedure to adjust the handlebar to the operator's requirements so that the machine could be easily handled.
LATERAL ADJUSTMENT : The lateral inclination of the handlebar allows the operator to keep off the cultivated ground and not to squash the
vegetation around.
Go on raising the lever (3) to unlock the handlebar (2) from the support (1). Turn the handlebar to the desired part and lower the lever (3) to lock it.
HEIGHT ADJUSTMENT : in order to unlock the handlebar (2) you need to turn the handles (4) to loosen them . Raise or lower the handlebar in the
desired position ( the standard adjustment is at the sides height/level ). To settle the right position, tighten the 2 handles (4).
INSTRUCTIONS
Following the assembly & adjustment operations the motor-hoe is ready to start working.
- Adjust the handlebar to the requested position/height (see fig. 12).
- Before switching the engine on, carefully check if the motor-hoe is in perfect good repair.
-Attention: the motor-hoe is delivered without the oil into the engine. The tank has got a capacity for about 0,5 kg. and should be filled in up to the
indicated level. In any case the operator should always carefully read the engine instructions manual.
- Do not change the calibration of the speeds control rotation device of the engine in order not to over-speed it.
IMPORTANT : at the first use of the machine it is absolutely necessary to verify that inside the chassis to be present the lubrication oil. Do no start
the unit/machine on before having done such control.
- When you have finished the assembly, switch the motor-hoe on and check , bringing the accelerator to stop position , the engine to shut completely
down.
- How to switch the engine on (Fig. 18 ): Open the fuel cap (for the engine equipped like this), push to START the accelerator lever on the handlebar
(1). If the engine is cold, operate the starter device on the carburettor, bring the starter handle (10) and pull energetically.
When the engine is on, after some bursts/bangs, put the starter again at rest position.
- How to connect the accessories/rotavator (Fig.13) in order to connect the tilling gear, grasp the handlebar (1) and press the safety button (2) which
is preventing the accidental connection of the tines. Lower the lever (3) till end its way.
- How to connect the gears (Fig. 14) in order to select the most suitable tilling gear according to the ground (1 for hard soil - 2 for less hard soil)
position the gears connection lever (1) in correspondence with the gear number shown on the gears tag display (2).
- How to connect the reverse gear (Fig. 14): in order to connect the reverse gear , position the lever (1) in correspondence with letter R on the
gears tag display (2).
ATTENTION (fig. 14) : in correspondence to letters N the tiller is on "neutral" position, i.e. tines are not turning.
ATTENTION (fig. 14) : in case the gears connection should be difficult to perform, lower the lever (3) and insert the required gear.
The present machine has been projected in order to lower to the minimum the vibrations and noise levels. Anyhow we can advise you to stop working
any now and then in case you would need to perform/work for a long period.
Stop working operation : To stop the work, switch the engine off, bring the accelerator lever (Fig. 18 part 1) into stop position.
HOW TO CHECK THE GEARBOX OIL LEVER ( fig. 15) :
the level : position the unit on a flat surface, take the small rod (1) and verify the level to be between min. and max level. Check the oil lever every
60 hours use.
HOW TO CHANGE THE GEARBOX OIL ( fig.16 )
The motor-hoe handlebar can be both side and height adjusted. Before starting any work it is a
inside the gearbox you can see oil (SAE 80 QT 0,90 lt) . In order to check
take the small rod off (1) position a bowl (B) ( min. capacity 1 lt) under the gearbox
