Eurosystems Euro5RG EVO Mode D'emploi page 19

5 - During working operations, for protection purposes, it is recommended to wear technical/strong shoes and long trousers. Be careful,
because when machine is operating the danger to be wounded in the toes or feet is really high. Walk, never run with the machine.
6 - During the machine transport and all the maintenance, cleaning, equipment change operations, the engine must be switched off.
7 - Before leaving the machine, please switch the engine off.
8 - Do not switch the machine on in closed rooms/areas where you can have carbon monoxide exhalations.
9 - WARNING ! The petrol/gasoline is highly inflammable. Store fuel only in containers specifically designed fort he storage of such materials.
Don't fill the tank neither in closed areas, nor when engine is on, don't smoke and be careful to the petrol/gasoline loss from the tank. In case
of leak, don't try to switch the engine on but move the machine away from the area in order to avoid ignition source until the gasoline vapours
fade away. Re-place the tank caps and the gasoline box.
10 - Keep attention to the exhaust pipe. The parts near the pipe can reach 80°C. Replace the defective and/or worn out silencers Burn
hazards !!!
11 - Do not work on excessively steep slopes and take every precaution when changing direction or pulling the machine towards you.
12 - Before putting the machine into operations, check it visually and make sure all the accident prevention measures are working. It is
absolutely forbidden to exclude and/or to tamper with them. Replace worn or damaged elements.
13 - In case the machine is incorrectly used, and/or the repairs are performed by non-authorized technical staff, and/or fitted by spare parts
other then original ones: any use other than that described above is prohibited and will involve the cancellation of the warranty and the refuse
all responsibility from the manufacturer.
SAFETY FEATURE (Fig.18)
automatically anytime the control lever (2) is released.
NOTES ON WORK WITH THE MOTOR-HOE
insert the spur into the soil. Lower the clutch lever (Fig. 18 part. 2) on the handlebar to allow the disks to bite into the soil. The motor-hoe will move
forwards when the handlebars are used to slightly lift the disks. The spur arm must always remain in the soil during work. Uses: Light or medium
textured soil working. Soil working (hoeing/breaking-up). Soil tillage (weeding). Ploughing in compost or fertilizers, etc. Attention: The motor-hoe is
unsuitable for working in soils covered by thick grass/lawns. It is also unadvisable to use the implement on stony soils.
TRANSPORT
A forklift truck should be used to move the machine. The forks should be opened as far as possible and inserted into the pallet. The
weight of the machine is given on the Manufacturer's data plate together with the other technical information.
HOW TO ASSEMBLE YOUR MOTOR-HOE
case. For assembly to be completed, the step/by/step procedure is as follows :
TRANSFER WHEEL (Fig. 2 A and 2 B) Take from the packing box the support wheel complete with wheel (1) and insert it in the front seat of the
frame (A). Fit the spring (2) and secure it with the washer (3) and the cotter pin (4) into the housing hole. The wheel support is in the transport position
as shown in Fig. 2A. To shift to work position pull it towards the wheel support (1) and turn it to the right until it stops. See fig. 2 B. The spring,
washer and cotter pin can be found inside the bag accessories.
SPUR (Fig. 3) Insert the spur (1) in correspondence of the hole of the frame (A). Secure with washer (2) and with the R pin (3) you can find in the
accessories bag.
All motor-hoes are provided with a safety feature which acts. The device causes the transmission to disconnect
With the engine running, rest the tines on the ground, and firmly holding the motor-hoe,
Unless otherwise agreed, the motor-hoe is delivered disassembled and placed in a packing
EN
19
