Tab. 2 :

Technical data

door code device
A
Technical data
Technical data
Feature
Supply voltage
Max. power consumption
Rated operating voltage
Max load capability
Freewheeling state voltage
Relay contact
· Max. switching voltage:
· Max. switching current:
Fuses
· primary
· secondary
Release time
Operating temperature
Humidity class according to
DIN 40040
Protection category according to
DIN EN 60529 2000-09
Casing
· Material:
· Shade:
Dimensions (W x H x D)
Important!
No potential-free relay contacts: Only use the internal voltage from terminals
1 – 2 for REL1 on terminals 3 – 5!
Characteristic
230V +/- 10%, 50–60Hz
9.5 VA
12 V – regulated
0.25 A
approx. 22 V
· 24 V
· 1 A
· Thermal fuse 130 °C
· 0.5 A slow-blow (small safety fuse
series 372/374; Wickmann, type TR. 5)
adjustable 1–30 seconds
0 °C to 40 °C
F
IP 30
· Aluminium die casting, powder-coated
· RAL 9002 grey white
120 mm x 145 mm x 57 mm
