7 liSt oF MaterialS

7.1

Display unit - Dp C01.rS232.7

7.1.1 Display accessories
Name
Ø 22.2 rubber clamping ring
(optional)
Ø 25.4 rubber clamping ring
(optional)
hex socket head cap screw
hex socket head cap screw
7.2

Drive unit - MM G33.350

7.2.1 Drive unit accessories
Name
Connector box
Cable clip
M6 nut
M6 bolt
DEALER MAnuAL Max Drive SySteM
Material No.
left display clamp 2316020400017
right display clamp 2316020400018
left display clamp 2316020400007
right display clamp 2316020400008
Material No.
1401080000097
1401300000001
1401080000101
1401080000099
LISt oF MAtERIALS
Quantity Specification
1
Ø 22.2
1
1
Ø 25.4
1
1 M3×8
2 M4×8
Quantity Specification
1
1
3 M6
3 M6
56
