Arrange the speed sensor and the magnet unit as shown by the picture above. Mount the magnet unit onto the spoke.
tighten up the mounting nut with a straight slot screwdriver. tightening torque: 1.5 – 2 nm
17
external speed sensor
A
magnet unit
b
PS01010702/
2308040000001
spoke
C
Mounting nut of the
D
magnet
PS01010701/
2327000000003
DEALER MAnuAL Max Drive SySteM
