Make sure that the cover is securely clicked into place. Screw the cover tightly onto the drive unit (see Figure 1).
If brake cables and gear cables are to be routed under the drive unit, bind
see Figure 2).
tightening torque: 1 nm
23
Figure 1
Figure 2
DEALER MAnuAL Max Drive SySteM
screw holes on the drive
C
unit's cover
end cover on the right
D
cable gatherer
e
1401150100005
cross head screw assem-
f
bly M3×8
1401020000127
together with a cable gatherer,
e
