5 Commissioning

Status display

Status display
Pos Colour Status
0
OFF
GREEN
BLINKING Function module is supplied with voltage but not connected to the
ON
RED BLINKING Internal error, Lenze setting has been loaded
ON
1
OFF
GREEN
BLINKING
ON
RED BLINKING No communication because time limit has been exceeded
ON
56
Notes
Function module is not supplied with voltage,
external voltage supply is switched off
controller.
Reason:
Standard device is
l
switched off
l
is being initialised
l
not available
Function module is supplied with voltage and is connected to the
standard device
Internal error of the function module
l
No connection to the master
l
Function module is not supplied with voltage.
Dup_Mac_ID" test phase. Not yet connected to master (scanner).
DeviceNet connection established.
Critical bus error
l
E82ZAFVC001E
