Equipment Description - Faro NISEA Basic Mode D'emploi

2
11
10
9
Fig. 2 – Rear view
12. Power supply
13. RS-232 port for external printer
14. LAN port *
15. Discharge tank drain connection for
main drain system *
16. Discharge tank vent
17. Feed tank vent
18. Solenoid valve for filling the feed
tank from the mains water supply *
(Allowable pressure from
20 kPa to 250 kPa)
Fig.3
VEDI Fig. 1
44
1. Display touch screen
2. Filtro bio-x

EQUIPMENT DESCRIPTION

19
8 7 6
20
1
2
3
4
5
21
20
14
12 13 15
Fig. 2 and Fig. 3
20. Data plate
* For the Premium version only
Fig. 1
1. Touch screen display
2. Bio-x filter
3. Motorised closure screw
4. USB port
5. Main switch
6. Feed tank filling connection
7. Discharge tank draining
connection
8. Feed tank draining connection
9. Manual feed tank emergency
filling connection
10. Nut screw for motorised
closure
11. Porthole
19. Dust filter *
21. Tray holder symbol
16
17 18
