Technical Data; Residual Risks - Scheppach Air Force 3 Traduction Des Instructions D'origine

22 Attention!
– This device can be used by children from 8 years
of age as well as by persons with reduced physi-
cal, sensory or mental capabilities or with a lack
of experience or knowledge, if they are supervised
or if they have been trained in the safe use of the
device and understand the resultant hazards.
– Children may not play with the device.
– Cleaning and maintenance may not be carried out
by children.
23 Supply hoses at pressures above 7 bar should be
equipped with a safety cable (e.g. a wire rope).
24 Avoid over-stressing the piping system by using flex-
ible hose connections to prevent kinking.
Warning! This electric tool generates an electromag-
netic field during operation. This field can impair active
or passive medical implants under certain conditions. In
order to prevent the risk of serious or deadly injuries, we
recommend that persons with medical implants consult
with their physician and the manufacturer of the medical
implant prior to operating the electric tool.
ADDITIONAL SAFETY INSTRUCTIONS
Safety instructions for working with compressed air
and blasting guns
• The compressor pump and lines can become very hot
during operation. Touching these parts will burn you.
• The air which is sucked in by the compressor must
be kept free of impurities that could cause fires or
explosions in the compressor pump.
• When releasing the hose coupling, hold the hose cou-
pling piece with your hand. This way, you can protect
yourself against injury from the rebounding hose.
• Wear safety goggles when working with the blow-out
pistol. Foreign bodies or blown off parts can easily
cause injuries.
• Do not blow at people with the blow-out pistol and
do not clean clothes while being worn. Risk of injury!
Safety information for paint spraying
• Do not process any paints or solvents with a flash
point below 55° C. There is a risk of explosion!
• Do not heat up paints or solvents. There is a risk of
explosion!
• If hazardous liquids are processed, wear protective
filter units (face guards). Also, adhere to the safety
information provided by the manufacturers of such
liquids.
• The details and designations of the Ordinance on
Hazardous Substances, which are displayed on the
outer packaging of the processed material, must be
observed.
• Additional protective measures are to be undertaken
if necessary, particularly the wearing of suitable cloth-
ing and masks.
• Do not smoke during the spraying process and/or in
the work area. There is a risk of explosion! Paint va-
pors are easily combustible.
• Never set up or operate the equipment in the vicin-
ity of a fire place, open lights or sparking machines.
• Do not store or eat food and drink in the work area.
Paint vapors are harmful to your health.
• The work area must exceed 30 m3 and sufficient ven-
tilation must be ensured during spraying and drying.
Do not spray against the wind. Always adhere to the
regulations of the local police authority when spraying
combustible or hazardous materials.
• Do not process media such as white spirit, butyl al-
cohol and methylene chloride with the PVC pressure
hose.These media will destroy the pressure hose.

Technical data

Mains connection
Motor rating W
Operating mode
Compressor speed min
-1
Operating pressure
Theoretical intake
capacity (l/min)
Sound power level L
WA
Uncertainty K
WA
Protection type
Protection class
Weight of the unit in kg
The noise emission values were measured in accord-
ance with EN ISO 3744.
Wear hearing protection.
The effects of noise can cause a loss of hearing.

Residual risks

Comply with the stipulated maintenance and safety in-
structions in the operating instructions.
Remain attentive at all times when working and keep
third parties at a safe distance from your work area.
Even when the device is being used properly, there will
always be certain residual hazards that cannot be com-
pletely ruled out. The following potential hazards can
arise due to the type and design of the device:
• Unintentional starting up of the product.
• Damage to hearing if the stipulated hearing protec-
tion is not worn.
• Dirt particles, dust etc. can get into the eyes or face
despite wearing safety goggles.
• Inhaling swirled up particles.
220 - 240 V~ 50 Hz
max. 1100
S3 15%
3750 min
-1
approx. 8 bar
approx. 180
97 dB(A)
1.93 dB
IP20
I
5
GB 15
