Operating pressure vessels
• You must keep your pressure vessel in good work-
ing order, operate the vessel correctly, monitor the
vessel, carry out necessary maintenance and re-
pair work immediately and meet the relevant safety
precautions.
• The supervisory authority may enforce essential
control measures in individual cases.
• A pressure vessel is not allowed to be used if it has
faults or deficiencies that can endanger workers
or third parties.
• Check the pressure vessel for signs of rust and
damage each time before using. Do not use the
compressor with a damaged or rusty pressure
vessel. If you discover any damage, then please
contact the customer service workshop.
Do not lose these safety instructions

6. Technical data

Mains connection
Motor rating
Operating mode
Compressor speed
Pressure vessel capacity
Operating pressure
Theoretical intake capacity
Sound power level L
WA
Uncertainty K
WA
Protection type
Weight of the unit
The noise emission values were measured in ac-
cordance with EN ISO 2151.
Wear hearing protection.
The effects of noise can cause a loss of hearing.

7. Before starting the equipment

Before you connect the equipment to the mains sup-
ply make sure that the data on the rating plate are
identical to the mains data.
• Check the equipment for damage which may have
occurred in transit. Report any damage immedi-
ately to the transport company which was used to
deliver the compressor.
• Install the compressor near the point of consump-
tion.
• Avoid long air lines and supply lines (extension
cables).
• Make sure that the intake air is dry and dust free.
• Do not install the compressor in a damp or wet
room.
22 | GB
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
230 V~ 50 Hz
max. 1500 W
S1
2850 min
-1
approx. 24 l
approx. 8 bar
approx. 220 l/min
93 dB(A)
2.4 dB
IP20
23 kg
• The compressor may only be used in suitable
rooms (with good ventilation and an ambient tem-
perature from +5 °C to 40 °C). There must be no
dust, acids, vapors, explosive gases or inflamma-
ble gases in the room.
• The compressor is designed to be used in dry
rooms. It is prohibited to use the compressor in
areas where work is conducted with sprayed water.

8. Attachment and operation

n Important!
You must fully assemble the appliance before
using it for the first time!
You will require the following tools for assembly and
installation: 2 x open-ended wrench size 13 mm (not
included)
8.1 Fitting the wheels (11)
• Fit the supplied wheels (11) as shown in Fig. 5.
8.2 Fitting the supporting foot (A)
• Fit the supplied supporting foot (A) as shown in Fig-
ure 6.
8.3 Installation of the air filter (15)
• Remove the transport plug (Figure 11 pos. F) and
attach the air filter (Figure 12/15) on the unit by
turning clockwise (N) (Figure 13).
• Solve for maintenance the air filter (15) by turning
counter-clockwise (M) (Figure 13).
8.4 Checking the oil level (Figure 8 - 10)
m Warning: For the first use, check the oil level of
the compressor.
1 Operating the machine without oil will cause irrep-
arable damage and render the warranty invalid.
2 Remove the plastic oil inlet plug on top of the
crank box of the compressor casing. (see fig. 8)
3 Check the oil level in the sight glass (18). The oil
level should be in the centre of the red circle. (see
fig. 10 pos. 18.1)
4 Attach the closing plug (14), which is included and
pull it tight.
8.5 Mains connection
• The compressor is equipped with a mains cable
with shock-proof plug. This can be connected to
any 230-240 V~ 50 Hz shock-proof socket which is
protected by a 16 A fuse.
• Before you use the machine, make sure that the
mains voltage is the same as the operating voltage
(see the rating plate).
• Long supply cables, extensions, cable reels etc.
cause a drop in voltage and can impede motor
start-up.
