6. Technical data

Mains connection
Motor rating
Operating mode
Compressor speed
Operating pressure
Theoretical intake
capacity
Sound power level L
WA
Uncertainty K
WA
Protection type
Protection class
Weight of the unit
The noise emission values were measured in ac-
cordance with EN ISO 3744.
Wear hearing protection.
The effects of noise can cause a loss of hearing.
Residual risks
Comply with the stipulated maintenance and safety
instructions in the operating instructions.
Remain attentive at all times when working and keep
third parties at a safe distance from your work area.
Even when the device is being used properly, there
will always be certain residual hazards that cannot
be completely ruled out. The following potential haz-
ards can arise due to the type and design of the
device:
• Unintentional starting up of the product.
• Damage to hearing if the stipulated hearing pro-
tection is not worn.
• Dirt particles, dust etc. can get into the eyes or
face despite wearing safety goggles.
• Inhaling swirled up particles.

7. Before starting the equipment

Before you connect the equipment to the mains sup-
ply make sure that the data on the rating plate are
identical to the mains data.
• Check the equipment for damage which may have
occurred in transit. Report any damage immedi-
ately to the transport company which was used to
deliver the compressor.
• Install the compressor near the point of consump-
tion.
• Avoid long air lines and supply lines (extension
cables).
• Make sure that the intake air is dry and dustfree.
• Do not install the compressor in a damp or wet
room.
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
220 - 240 V~ 50 Hz
max. 1100 W
S3 15%
3750 min
-1
approx. 8 bar
approx. 180 (l/min)
97 dB(A)
1.93 dB
IP20
II
5.5 kg
• The compressor may only be used in suitable
rooms (with good ventilation and an ambient tem-
perature from +5 °C to 40 °C). There must be no
dust, acids, vapors, explosive gases or inflamma-
ble gases in the room.
• The compressor is designed to be used in dry
rooms. It is prohibited to use the compressor in
areas where work is conducted with sprayed water.

8. Attachment and operation

m Important!
You must fully assemble the appliance before
using it for the first time!
Mains connection
• The compressor can be connected to any 220 -
240-240 V~ 50 Hz shock-proof socket which is pro-
tected by a 16 A fuse.
• Before you use the machine, make sure that the
mains voltage is the same as the operating voltage
(see the rating plate).
• Long supply cables, extensions, cable reels etc.
cause a drop in voltage and can impede motor
start-up.
• At low temperatures below +5°C, sluggishness
may make starting difficult or impossible.
ON/OFF switch (fig. 1)
• To switch on the compressor, press the button (2)
on position I.
• To switch off the compressor, press the button (2)
on position 0.
Establishing connections (fig. 3, 4)
m Attention! Switch the device off for this.
When doing so, hold the coupling firmly in order to
avoid injuries due to the hose springing back.
• Connect the fitting of your compressed air tool to
the compressed air hose (5) of the compressor.
• To disconnect this coupling again, pull the quick-
coupling (4) back at the compressed air hose (5).
Using the tyre inflation device (fig. 6, 7, 8)
The compressed air tyre inflation device (G) is used
to inflate car tyres. With the corresponding accesso-
ries it can also be used to inflate and regulate bicycle
tyres, inflatable dinghies, air mattresses, balls etc.
Pressure can be released by actuating the vent valve
(7).
m Attention! The manometer has not been officially
calibrated! After inflating, please check the air pres-
sure with a calibrated device.
Using an air blow gun
You can also use the tyre inflation device (G) as an
air blow gun to clean out cavities and to clean soiled
surfaces and work equipment.
